glTF 模型

AMap.GltfLoader 插件解析加载 glTF 模型

源代码编辑器

复制

运行

还原

          <!DOCTYPE HTML>
<html>
<head>
    <meta charset="utf-8">
    <meta http-equiv="X-UA-Compatible" content="IE=edge">
    <meta name="viewport" content="initial-scale=1.0, user-scalable=no, width=device-width">
    <link rel="stylesheet" href="http://a.amap.com/jsapi_demos/static/demo-center/css/demo-center.css" />

    <title>glTF 模型</title>
    <style>
        html,
        body,
        #container {
            margin: 0;
            padding: 0;
            width: 100%;
            height: 100%;
        }

        .cc {
            position: absolute;
            color: #000000;
            bottom: 10px;
            left: 10px;
        }
    </style>
    <script>
        delete window.AMap;
    </script>
</head>
<body onLoad="mapInit()">
<div id="container"></div>
<div class="cc">shanghai city 3D models by Michael Zhang /
    <a target='_blank' href="https://creativecommons.org/licenses/by/2.0/">CC BY </a>
</div>
<script src="http://webapi.amap.com/maps?v=1.4.15&key=您申请的key值&plugin=Map3D"></script>
<script src="http://a.amap.com/jsapi_demos/static/demo-center/js/demoutils.js"></script>

<script>
    function mapInit() {
        // 创建地图实例
        var map = new AMap.Map("container", {
            viewMode: '3D',
            pitch: 30,
            rotation: 25,
            zoom: 16,
            center: [121.499809, 31.236666],
          	showBuildingBlock: false,
            mapStyle: 'amap://styles/macaron',
            showIndoorMap: false
        });

        // 创建Object3DLayer图层
        var object3Dlayer = new AMap.Object3DLayer();
        map.add(object3Dlayer);

        var druckMeshes, cityMeshes;


        map.plugin(["AMap.GltfLoader"], function () {
            var urlCity = 'http://a.amap.com/jsapi_demos/static/gltf-online/shanghai/scene.gltf';
            var urlDuck = 'http://a.amap.com/jsapi_demos/static/gltf/Duck.gltf';
            var paramCity = {
                position: new AMap.LngLat(121.510909, 31.233366), // 必须
                scale: 3580, // 非必须，默认1
                height: 1800,  // 非必须，默认0
                scene: 0, // 非必须，默认0
            };

            var paramDuck = {
                position: new AMap.LngLat(121.495000, 31.233366), // 必须
                scale: 800, // 非必须，默认1
                height: -100,  // 非必须，默认0
                scene: 0, // 非必须，默认0
            };

            var gltfObj = new AMap.GltfLoader();

            gltfObj.load(urlCity, function (gltfCity) {
                cityMeshes = gltfCity;
                gltfCity.setOption(paramCity);
                gltfCity.rotateX(90);
                gltfCity.rotateZ(120);
                object3Dlayer.add(gltfCity);
            });

            gltfObj.load(urlDuck, function (gltfDuck) {
                druckMeshes = gltfDuck;
                gltfDuck.setOption(paramDuck);
                gltfDuck.rotateX(90);
                gltfDuck.rotateZ(-20);
                object3Dlayer.add(gltfDuck);
            });

        });

        // 给gltf模型绑定事件
        map.on('click', function (ev) {
            var pixel = ev.pixel;
            var px = new AMap.Pixel(pixel.x, pixel.y);
            var obj = map.getObject3DByContainerPos(px, [object3Dlayer], false) || {};
            if (obj && obj.object) {
                var meshId = obj.object.id;
                if(druckMeshes && druckMeshes.layerMesh){
                    for(var i = 0; i < druckMeshes.layerMesh.length; i++) {
                        if(meshId === druckMeshes.layerMesh[i].id){
                            return log.info("您点击了小黄鸭模型！");
                        }
                    }
                }

                if(cityMeshes && cityMeshes.layerMesh){
                    for(var i = 0; i < cityMeshes.layerMesh.length; i++) {
                        if(meshId === cityMeshes.layerMesh[i].id){
                            return log.info("您点击了陆家嘴模型！");
                        }
                    }
                }

            }

        });
    }
</script>
</body>
</html>
